CDI MULTITEST "Premier" Calibration System, 2000-1

$111,969.16

Quick Overview

CDI MULTITEST "Premier" Calibration System, 2000-1

Details

 MULTITEST Torque, Force and Tension  "Premier" Calibration System

CDI's All Inclusive Calibration System - Part Number 539-2000-1

  • Our most comprehensive calibration system for torque and force
  • Calibrate torque wrenches up to 2000 ft. lbs.
  • Check the accuracy and calibrate cable tensiometers, tension and compression gauges
  • Includes the easy-to-use 4-in-1 transducer kit
  • Eleven single transducers ranging from 5 in. oz. up to 2000 ft. lbs.
  • Includes torque screwdriver testing kit
  • Automatic safety feature locks system to prevent overloading and possible damage to transducers
  • Displays eight units of torque and six units of force
  • Also includes a calibration stand and all necessary calibration wheels, arms, weights and trays
  • Downloading software included

The World's Most Complete System.  Part Number 539-2000-1 consists of the following:

  • Part Number                      Description
  • 2000-610-02                     MULTITEST Monitor
  • 2000-600-02                     Mechanical Loader 2000 ft.lb. capacity
  • 2000-100-02                     Roller Cabinet
  • 2000-400-02                     4-in-1 Transducer Kit, 4 - 250 in.lb.
  • 2000-500-02                     4-in-1 Transducer Adapter Kit
  • 2000-4-02                        Transducer Range from 5 - 50 in.oz.
  • 2000-5-02                        Transducer Range from 15 - 200 in.oz.
  • 2000-6-02                        Transducer Range from 4 - 50 in.lb.
  • 2000-65-02                      Transducer Range from 15 - 150 in.lb.
  • 2000-7-02                        Transducer Range from 30 - 400 in.lb.
  • 2000-8-02                        Transducer Range from 80 - 1000 in.lb.
  • 2000-10-02                       Transducer Range from 10 - 125 ft.lb.
  • 2000-11-02                       Transducer Range from 20 - 250 ft.lb.
  • 2000-12-02                       Transducer Range from 60 - 600 ft.lb.
  • 2000-13-02                       Transducer Range from 100 - 1000 ft.lb.
  • 2000-14-02                       Transducer Range from 200 - 2000 ft.lb.
  • 900-0-1KIT                        Transducer Range from 20 - 250 ft.lb.
  • 900-2-01KIT                      Joint Rate Simulator 400 in.lb. capacity
  • 900-3-01KIT                      Joint Rate Simulator 1000 in.lb. capacity
  • 2000-550-02                      Extension Arm Kit for Long Torque Wrenches
  • 2000-750-02                      Torque Screwdriver Testing Kit
  • 2000-320-0                        No. 1 Weight Set
  • 2500-50-0                          2-1/2" Calibration Wheel
  • 2000-151-0                        5" Calibration Wheel
  • 2000-152-0                        10" Butterfly Wheel
  • 2000-154-0                        40" Calibration Arm
  • 390-2-2                             4 oz. Weight Hanger
  • 2000-301                           8 oz. Weight Hanger
  • 2000-304-0                        7.5 lb. Weight Hanger
  • 2000-302-0                        15 lb. Weight Hanger
  • 2000-303-0                        50 lb. Weight Hanger
  • 2000-250-02                      Calibration Stand Kit
  • 2000-260-0                        Tensiometer Testing Kit
  • 2000-261-0                        Tension Gauge Testing Kit
  • 2000-262-0                        Compression Gauge Testing Kit
  • 2000-263-02                       Force Arm Kit
  • 2000-SW                            PC Software
  • 2000-50-1                          Cable from MULTITEST to PC

The MULTITEST Calibration System can be ordered several ways. Each system begins with the same three basic components: the Multitest Digital Monitor, the Roller Cabinet and the 2000 ft.lb. Mechanical Loader. We offer three different systems, the "Premier" (described above), the "Supreme" and the "Basic". These systems and their components are described in detail with each model.

In addition, you may order any component separately to build your own "custom" system.  Contact BlueTools.com to discuss your torque calibration needs.
